Rabbit Litter Box
A self-cleaning litter box made for rabbits, not cats. Poop falls through a grate onto a belt that carries it to a back drawer. Pee soaks into a full-size puppy pad, and the box swaps in a fresh pad on its own. Hay stays in the box, where rabbits want it.
Loading model
Drag to turn. Scroll or pinch to zoom.
Size
- Outside size
- 33 W x 37 D x 20.4 H in
- Standing area
- 31 x 23 in
- Floor height
- 9.5 in (step at 8.4 in)
- Pads loaded
- 10
- Poop drawers
- 1, each 30 x 6 in
- Hay rack
- 31 in long
Views
Still open
- 1.
Pick one lane or two. One lane fits through a door and matches the first build step.
- 2.
The pad tray cannot slide out the back yet. The guide that turns the pad onto the belt is in the way.
- 3.
Pads are full 30 x 23 in sheets. Each lane got 1 in taller to fit a flat tray of 10 under the belt.
